Fix 955 Multi Point Lock - Supply and Fit Only

• Product Code: R3004
• Availability: Order Period

Description

•    Multi point lock for terrace doors
•    Used for outward opening doors
•    Lockable with 90 degree key turn
•    Lockable with oval cylinder
•    Face place 25 x 2 mm
•    Back set 50 mm
•    Length - 1850mm
•    Centres/PZ 105mm
•    Three wedge bolts
•    Not handed

Operation and features
When the door is unlocked the wedge bolts are retracted. The handle is pointed downwards and is lifted to the horizontal position to open the door. Locking is done by turning the handle down and then using a key or thumb turn.

Note: Only the main espag part available for sale, the upper short transmission part is not available.

Accessories
•    Oval cylinder - see Locks & Cylinders page
•    Handles - see Door Handles page
